Kingbright AM2520EF/4ID5V
LED CBI 1.8MM QUAD RED VERT
Answer first: this page is a purchasing reference for the exact part number AM2520EF/4ID5V from Kingbright. Use it to start datasheet, package, manufacturer and RFQ verification; do not treat page text as a live stock, price or lead-time promise.
Key Parameters
| Part Number | AM2520EF/4ID5V |
|---|---|
| Manufacturer | Kingbright |
| Category | Circuit Board Indicators, Arrays, Light Bars, Bar Graphs |
| series | - |
| packaging | Tube |
| product status | Active |
| param 1 | Red (x 4) |
| param 2 | 627nm |
| param 3 | 4 Wide |
| param 4 | 18mA |
| param 5 | 8mcd |
| param 6 | 40° |
| param 7 | Diffused, Tinted |
| param 8 | Round with Domed Top |
| param 9 | 1.80mm Dia |
| param 10 | 5V |
| param 11 | Through Hole |
Parameters are provided for purchasing review. Confirm package, suffix, lifecycle status, datasheet revision and approved substitutes before ordering.
How to Verify AM2520EF/4ID5V Before Ordering
Datasheet and parameter checks
- Confirm the full manufacturer part number, not only a shortened search keyword.
- Compare package, pinout, dimensions, voltage or rating fields, temperature range and compliance wording against the released BOM.
- Use the manufacturer datasheet or drawing for electrical and mechanical limits before approving a substitute.
RFQ fields SENICO needs
- Send exact part number, manufacturer, quantity, target delivery date, destination and required packaging.
- State whether alternates are allowed, and list any date-code, certificate, traceability or customer AVL requirement.
- Keep exact stock, factory lead time and proposed alternatives in separate quote lanes.
For AM2520EF/4ID5V, SENICO recommends checking manufacturer marking, package, date code, requested quantity, approved vendor requirements and replacement risk before issuing a purchase order. If a supplier suggests an equivalent, record the changed fields and approval owner before comparing price.
We do not treat displayed data as a real-time stock or price commitment. The RFQ reply is the verified commercial reference.
