Vishay General Semiconductor - Diodes Division VS-P105W
SCR HY-BRIDGE 1200V 25A PACE-PAK
Answer first: this page is a purchasing reference for the exact part number VS-P105W from Vishay General Semiconductor - Diodes Division. Use it to start datasheet, package, manufacturer and RFQ verification; do not treat page text as a live stock, price or lead-time promise.
Key Parameters
| Part Number | VS-P105W |
|---|---|
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Category | SCRs - Modules |
| package | 8-PACE-PAK |
| series | - |
| packaging | Bulk |
| product status | Active |
| param 1 | Bridge, Single Phase - SCRs/Diodes (Layout 1) |
| param 2 | 2 SCRs, 2 Diodes |
| param 3 | 1.2 kV |
| param 4 | - |
| param 5 | - |
| param 6 | 2 V |
| param 7 | 60 mA |
| param 8 | 357A, 375A |
| param 9 | 130 mA |
| param 10 | -40°C ~ 125°C (TJ) |
| param 11 | - |
| param 12 | - |
| param 13 | Chassis Mount |
Parameters are provided for purchasing review. Confirm package, suffix, lifecycle status, datasheet revision and approved substitutes before ordering.
How to Verify VS-P105W Before Ordering
Datasheet and parameter checks
- Confirm the full manufacturer part number, not only a shortened search keyword.
- Compare package, pinout, dimensions, voltage or rating fields, temperature range and compliance wording against the released BOM.
- Use the manufacturer datasheet or drawing for electrical and mechanical limits before approving a substitute.
RFQ fields SENICO needs
- Send exact part number, manufacturer, quantity, target delivery date, destination and required packaging.
- State whether alternates are allowed, and list any date-code, certificate, traceability or customer AVL requirement.
- Keep exact stock, factory lead time and proposed alternatives in separate quote lanes.
For VS-P105W, SENICO recommends checking manufacturer marking, package, date code, requested quantity, approved vendor requirements and replacement risk before issuing a purchase order. If a supplier suggests an equivalent, record the changed fields and approval owner before comparing price.
We do not treat displayed data as a real-time stock or price commitment. The RFQ reply is the verified commercial reference.
