Aluminum - Polymer Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Type | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Ratings | Applications | Features | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PLF0E561MCO1TDCAP ALUM POLY 560UF 20% 2.5V TH Nichicon |
108,337 |
|
Datasheet |
 |
PLF | Tape & Box (TB) | Active | Polymer | 560 µF | ±20% | 2.5 V | 6mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 240 mA @ 120 Hz | 4.8 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.374" (9.50mm) | - | Through Hole |
|
PLF0E681MDL1TDCAP ALUM POLY 1,500UF 20% 10V SM Nichicon |
163,695 |
|
- |
|
- | Tape & Box (TB) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PLF0E681MCO1TDCAP ALUM POLY 47UF 20% 20V SMD Nichicon |
193,462 |
|
Datasheet |
|
- | Tape & Box (TB) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
RL80J561MDN1PXCAP ALUM POLY 560UF 20% 6.3V TH Nichicon |
100,743 |
|
Datasheet |
|
FPCAP, RL8 | Tape & Box (TB) | Active | Polymer | 560 µF | ±20% | 6.3 V | 8mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 570 mA @ 120 Hz | 5.7 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
RL80J681MDN1PXCAP ALUM POLY 680UF 20% 6.3V TH Nichicon |
175,039 |
|
Datasheet |
|
FPCAP, RL8 | Tape & Box (TB) | Active | Polymer | 680 µF | ±20% | 6.3 V | 8mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 570 mA @ 120 Hz | 5.7 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
RR70E681MDM1CAP ALUM POLY 270UF 20% 35V SMD Nichicon |
179,087 |
|
- |
|
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
RE50E821MDN1KXCAP ALUM POLY 820UF 20% 2.5V TH Nichicon |
156,509 |
|
Datasheet |
|
FPCAP, RE5 | Tape & Box (TB) | Active | Polymer | 820 µF | ±20% | 2.5 V | 5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 630 mA @ 120 Hz | 6.3 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
RE50E821MDN1PXCAP ALUM POLY 820UF 20% 2.5V TH Nichicon |
145,283 |
|
Datasheet |
|
FPCAP, RE5 | Tape & Box (TB) | Active | Polymer | 820 µF | ±20% | 2.5 V | 5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 630 mA @ 120 Hz | 6.3 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
RE50G561MDN1KXCAP ALUM POLY 560UF 20% 4V TH Nichicon |
156,890 |
|
Datasheet |
|
FPCAP, RE5 | Tape & Box (TB) | Active | Polymer | 560 µF | ±20% | 4 V | 5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 630 mA @ 120 Hz | 6.3 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
RE50G561MDN1PXCAP ALUM POLY 560UF 20% 4V TH Nichicon |
148,601 |
|
Datasheet |
|
FPCAP, RE5 | Tape & Box (TB) | Active | Polymer | 560 µF | ±20% | 4 V | 5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 630 mA @ 120 Hz | 6.3 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
