Aluminum - Polymer Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Type | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Ratings | Applications | Features | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RNU1E391MDN1CAP ALUM POLY 390UF 20% 25V TH Nichicon |
112,266 |
|
Datasheet |
 |
FPCAP, RNU | Bulk | Active | Polymer | 390 µF | ±20% | 25 V | 14mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 500 mA @ 120 Hz | 5 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole |
|
PCR1D101MCL1GSCAP ALUM POLY 100UF 20% 20V SMD Nichicon |
190,406 |
|
Datasheet |
|
PCR | Tape & Reel (TR) | Obsolete | Polymer | 100 µF | ±20% | 20 V | 41mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 1.3 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.240" (6.10mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
PCR1E101MCL4GSCAP ALUM POLY 100UF 20% 25V SMD Nichicon |
155,702 |
|
Datasheet |
|
PCR | Tape & Reel (TR) | Obsolete | Polymer | 100 µF | ±20% | 25 V | 27mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 1.6 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.315" (8.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
PCR1A181MCL1GSCAP ALUM POLY 180UF 20% 10V SMD Nichicon |
194,314 |
|
Datasheet |
|
PCR | Tape & Reel (TR) | Obsolete | Polymer | 180 µF | ±20% | 10 V | 34mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 1.4 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.240" (6.10mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
PCR1D151MCL4GSCAP ALUM POLY 150UF 20% 20V SMD Nichicon |
144,791 |
|
Datasheet |
|
PCR | Tape & Reel (TR) | Obsolete | Polymer | 150 µF | ±20% | 20 V | 25mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 1.7 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.315" (8.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
PCS0G151MCL1GSCAP ALUM POLY 150UF 20% 4V SMD Nichicon |
130,446 |
|
Datasheet |
|
PCS | Tape & Reel (TR) | Active | Polymer | 150 µF | ±20% | 4 V | 25mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | General Purpose | - | - | 2.2 A @ 100 kHz | - | - | 0.197" Dia (5.00mm) | 0.236" (6.00mm) | 0.209" L x 0.209" W (5.30mm x 5.30mm) | Surface Mount |
|
RVB0G221MNGCAP ALUM POLY 220UF 20% 4V SMD Nichicon |
140,139 |
|
Datasheet |
|
FPCAP, VB | Tape & Reel (TR) | Obsolete | Polymer | 220 µF | ±20% | 4 V | 15mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.118" (3.00mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
|
|
RNU1E391MDNASQCAP ALUM POLY 390UF 20% 25V TH Nichicon |
129,458 |
|
Datasheet |
|
FPCAP, RNU | Bulk | Active | Polymer | 390 µF | ±20% | 25 V | 14mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 500 mA @ 120 Hz | 5 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole |
|
RHS1D391MCN1GSCAP ALUM POLY 390UF 20% 20V SMD Nichicon |
197,010 |
|
Datasheet |
|
FPCAP, RHS | Tape & Reel (TR) | Active | Polymer | 390 µF | ±20% | 20 V | 14mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 495 mA @ 120 Hz | 4.95 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
PLF0G561MCO6TDCAP ALUM POLY 560UF 20% 4V TH Nichicon |
186,977 |
|
Datasheet |
|
PLF | Cut Tape (CT) | Active | Polymer | 560 µF | ±20% | 4 V | 7mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 5.2 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
