Aluminum - Polymer Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Type | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Ratings | Applications | Features | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL218097403E3CAP ALUM POLY 150UF 20% 10V SMD Vishay Beyschlag/Draloric/BC Components |
184,721 |
|
Datasheet |
 |
180 CPS | Tape & Reel (TR) | Active | Polymer | 150 µF | ±20% | 10 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.8 A @ 100 kHz | 15 mOhms | - | 0.248" Dia (6.30mm) | 0.303" (7.70mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
MAL218597106E3CAP ALUM POLY 68UF 20% 50V SMD Vishay Beyschlag/Draloric/BC Components |
122,384 |
|
- |
|
185 CPNZ | Box | Active | Polymer | 68 µF | ±20% | 50 V | 30mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 150 mA @ 120 Hz | 3 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | - | Surface Mount |
|
MAL218397804E3CAP ALUM HYBRID 56UF 20% 63V SMD Vishay Beyschlag/Draloric/BC Components |
162,755 |
|
Datasheet |
|
183 CPHT | Box | Active | Hybrid | 56 µF | ±20% | 63 V | 30mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | 140 mA @ 120 Hz | 1.4 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
|
MAL218397105E3CAP ALUMHYB 100UF 20% 50V SMD Vishay Beyschlag/Draloric/BC Components |
113,265 |
|
Datasheet |
|
183 CPHT | Box | Active | Hybrid | 100 µF | ±20% | 50 V | 28mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | 160 mA @ 120 Hz | 1.6 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.425" (10.80mm) | - | Surface Mount |
|
MAL218297006E3CAP ALUMHYB 270UF 20% 35V SMD Vishay Beyschlag/Draloric/BC Components |
161,501 |
|
Datasheet |
|
182 CPHZ | Box | Active | Hybrid | 270 µF | ±20% | 35 V | 20mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | - | Automotive | - | 250 mA @ 120 Hz | 2.5 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.425" (10.80mm) | - | Surface Mount |
|
MAL218697554E3CAP ALUM POLY 180UF 20% 20V SMD Vishay Beyschlag/Draloric/BC Components |
106,081 |
|
Datasheet |
|
186 CPNT | Tape & Reel (TR) | Active | Polymer | 180 µF | ±20% | 20 V | 25mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | - | 3.8 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.315" L x 0.315" W (8.00mm x 8.00mm) | Surface Mount |
|
MAL218497109E3CAP ALUM POLY 100UF 20% 50V SMD Vishay Beyschlag/Draloric/BC Components |
178,869 |
|
- |
|
184 CPNS | Box | Active | Polymer | 100 µF | ±20% | 50 V | 25mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 150 mA @ 120 Hz | 3 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | - | Surface Mount |
|
|
MAL218097705E3CAP ALUM POLY 560UF 20% 4V SMD Vishay Beyschlag/Draloric/BC Components |
122,971 |
|
Datasheet |
|
180 CPS | Tape & Reel (TR) | Active | Polymer | 560 µF | ±20% | 4 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3.22 A @ 100 kHz | 22 mOhms | - | 0.315" Dia (8.00mm) | 0.264" (6.70mm) | 0.331" L x 0.331" W (8.40mm x 8.40mm) | Surface Mount |
|
MAL218197502E3CAP ALUM POLY 68UF 20% 16V SMD Vishay Beyschlag/Draloric/BC Components |
140,913 |
|
Datasheet |
|
181 CPL | Tape & Reel (TR) | Active | Polymer | 68 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.2 A @ 100 kHz | 30 mOhms | - | 0.236" Dia (6.00mm) | 0.232" (5.90mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
MAL218697607E3CAP ALUM POLY 120UF 20% 25V SMD Vishay Beyschlag/Draloric/BC Components |
102,271 |
|
Datasheet |
|
186 CPNT | Tape & Reel (TR) | Active | Polymer | 120 µF | ±20% | 25 V | 25mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | - | 3.8 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.315" L x 0.315" W (8.00mm x 8.00mm) | Surface Mount |
