DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
E1225M05B2-FSRFAN AXIAL 120X25MM 5VDC WIRE |
2,704 |
|
Datasheet |
 |
E1225 | Bulk | Active | 5VDC | Square - 120mm L x 120mm H | 25.00mm | 67.0 CFM (1.88m³/min) | 0.180 in H2O (45.0 Pa) | Ball | Tubeaxial | Locked Rotor Sensor, Thermal Overload Protector (TOP) | 36.0dB(A) | - | 2200 RPM | 3 Wire Leads | - | - | CE, cUL, TUV, UL | 0.436 lb (197.77 g) |
|
MC8038E48B2-FSRFAN AXIAL 80X38MM 48VDC WIRE |
3,744 |
|
Datasheet |
|
MC8038 | Bulk | Active | 48VDC | Square - 80mm L x 80mm H | 38.00mm | 81.5 CFM (2.28m³/min) | 0.840 in H2O (209.2 Pa) | Ball | Tubeaxial | Locked Rotor Sensor, Thermal Overload Protector (TOP) | 52.1dB(A) | - | 5800 RPM | 3 Wire Leads | - | - | cUL, TUV, UL | 0.397 lb (180.08 g) |
|
MC8038U12B2-FSRFAN AXIAL 80X38MM 12VDC WIRE |
2,607 |
|
Datasheet |
|
MC8038 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 38.00mm | 95.6 CFM (2.68m³/min) | 1.150 in H2O (286.5 Pa) | Ball | Tubeaxial | Locked Rotor Sensor, Thermal Overload Protector (TOP) | 60.2dB(A) | - | 6800 RPM | 3 Wire Leads | - | - | cUL, TUV, UL | 0.397 lb (180.08 g) |
|
|
DC0251012M2B-3T1FAN 25X10MM 12VDC TACH COMPUTER |
2,804 |
|
Datasheet |
|
- | Bulk | Active | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 1.9 CFM (0.053m³/min) | 0.170 in H2O (42.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 24.0dB(A) | 720 mW | 10000 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
DC0251012L2B-3T1FAN 25X10MM 12VDC TACH COMPUTER |
4,196 |
|
Datasheet |
|
- | Bulk | Active | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 1.3 CFM (0.036m³/min) | 0.070 in H2O (17.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.0dB(A) | 600 mW | 7000 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
DC0301012U2B-3T1FAN 30X10MM 12VDC TACH COMPUTER |
4,571 |
|
Datasheet |
|
- | Bulk | Active | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 5.7 CFM (0.157m³/min) | 0.240 in H2O (59.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 31.0dB(A) | 1.08 W | 11000 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
DC0922512U2B-3T1FAN 92X25MM 12VDC TACH COMPUTER |
2,270 |
|
Datasheet |
|
- | Bulk | Active | 12VDC | Square - 92mm L x 92mm H | 25.00mm | 69.2 CFM (1.94m³/min) | 0.280 in H2O (69.7 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 45.0dB(A) | 3.6 W | 3800 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
MR9238E48B-FSRFAN AXIAL 92X38MM 48VDC WIRE |
4,630 |
|
Datasheet |
|
MR9238 | Box | Active | 48VDC | Square - 92mm L x 92mm H | 38.00mm | 173.0 CFM (4.84m³/min) | 1.540 in H2O (383.6 Pa) | Ball | Tubeaxial | Auto Restart | 63.3dB(A) | - | 8000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
MR9238L12B-FSRFAN AXIAL 92X38MM 12VDC WIRE |
2,346 |
|
Datasheet |
|
MR9238 | Box | Active | 12VDC | Square - 92mm L x 92mm H | 38.00mm | 109.2 CFM (3.06m³/min) | 0.610 in H2O (151.9 Pa) | Ball | Tubeaxial | Auto Restart | 50.5dB(A) | - | 5000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
MR9238L24B-FSRFAN AXIAL 92X38MM 24VDC WIRE |
4,837 |
|
Datasheet |
|
MR9238 | Box | Active | 24VDC | Square - 92mm L x 92mm H | 38.00mm | 109.2 CFM (3.06m³/min) | 0.610 in H2O (151.9 Pa) | Ball | Tubeaxial | Auto Restart | 50.5dB(A) | - | 5000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
MR9238L48B-FSRFAN AXIAL 92X38MM 48VDC WIRE |
3,150 |
|
Datasheet |
|
MR9238 | Box | Active | 48VDC | Square - 92mm L x 92mm H | 38.00mm | 109.2 CFM (3.06m³/min) | 0.610 in H2O (151.9 Pa) | Ball | Tubeaxial | Auto Restart | 50.5dB(A) | - | 5000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
MR9238M48B-FSRFAN AXIAL 92X38MM 48VDC WIRE |
2,239 |
|
Datasheet |
|
MR9238 | Box | Active | 48VDC | Square - 92mm L x 92mm H | 38.00mm | 131.0 CFM (3.67m³/min) | 0.880 in H2O (219.2 Pa) | Ball | Tubeaxial | Auto Restart | 55.4dB(A) | - | 6000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
MR9238S12B-FSRFAN AXIAL 92X38MM 12VDC WIRE |
2,741 |
|
Datasheet |
|
MR9238 | Box | Active | 12VDC | Square - 92mm L x 92mm H | 38.00mm | 88.0 CFM (2.46m³/min) | 0.400 in H2O (99.6 Pa) | Ball | Tubeaxial | Auto Restart | 45.3dB(A) | - | 4000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.437 lb (198.00 g) |
|
|
PF36281B1-000U-A99Thermal Products |
4,989 |
|
Datasheet |
|
PF | Bulk | Active | 12VDC | Square - 36mm L x 36mm H | 28.00mm | 18.1 CFM (0.507m³/min) | 1.620 in H2O (403.5 Pa) | Ball | Tubeaxial | Auto Restart | 55.7dB(A) | 5.4 W | 18400 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
|
PF36281BX-000U-A99Thermal Products |
2,726 |
|
Datasheet |
|
PF | Bulk | Active | 12VDC | Square - 36mm L x 36mm H | 28.00mm | 22.8 CFM (0.638m³/min) | 2.550 in H2O (635.2 Pa) | Ball | Tubeaxial | Auto Restart | 61.9dB(A) | 9.6 W | 23000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CUR, TUV, UL | - |
|
|
9GA0312P3G0011FAN AXIAL 38X28MM 12VDC WIRE |
2,660 |
|
Datasheet |
|
San Ace 38 | Box | Active | 12VDC | Square - 38mm L x 38mm H | 28.00mm | 15.9 CFM (0.445m³/min) | 1.850 in H2O (460.8 Pa) | Ball | Tubeaxial | PWM Control, Speed Sensor (Tach) | 53.0dB(A) | 4 W | 19000 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.115 lb (52.16 g) |
|
|
9GA0312P3J0011FAN AXIAL 38X28MM 12VDC WIRE |
3,122 |
|
Datasheet |
|
San Ace 38 | Box | Active | 12VDC | Square - 38mm L x 38mm H | 28.00mm | 20.1 CFM (0.563m³/min) | 2.891 in H2O (720.1 Pa) | Ball | Tubeaxial | PWM Control, Speed Sensor (Tach) | 57.5dB(A) | 6.2 W | 23500 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.115 lb (52.16 g) |
|
|
MS1238M12B-FHRFAN AXIAL 120X38MM 12VDC WIRE |
2,631 |
|
Datasheet |
|
MS1238 | Bulk | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 125.0 CFM (3.50m³/min) | 0.240 in H2O (59.8 Pa) | Ball | Tubeaxial | Auto Restart | 46.0dB(A) | - | 2500 RPM | 2 Wire Leads | - | - | - | 0.667 lb (302.55 g) |
|
|
MS1238H12B-FHRFAN AXIAL 120X38MM 12VDC WIRE |
4,786 |
|
Datasheet |
|
MS1238 | Bulk | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 203.3 CFM (5.69m³/min) | 0.590 in H2O (147.0 Pa) | Ball | Tubeaxial | Auto Restart | 56.0dB(A) | - | 4000 RPM | 2 Wire Leads | - | - | - | 0.667 lb (302.55 g) |
|
|
MS1238E12B-FHRFAN AXIAL 120X38MM 12VDC WIRE |
2,039 |
|
Datasheet |
|
MS1238 | Bulk | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 271.1 CFM (7.59m³/min) | 1.190 in H2O (296.4 Pa) | Ball | Tubeaxial | Auto Restart | 68.0dB(A) | - | 5000 RPM | 2 Wire Leads | - | - | - | 0.667 lb (302.55 g) |
