DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
ODB600-24LBDC BLOWER 24V 120X31MM |
2,937 |
|
Datasheet |
 |
ODB600PT | Bulk | Active | 24VDC | Square/Rounded - 120.5mm L x 120.5mm H | 31.00mm | 20.0 CFM (0.560m³/min) | 0.350 in H2O (87.2 Pa) | Ball | Blower | Auto Restart, Locked Rotor Protection | 30.0dB(A) | - | 1800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus | - |
|
|
ODB600-48MBDC BLOWER 48V 120X31MM |
2,616 |
|
Datasheet |
|
ODB600PT | Bulk | Active | 48VDC | Square/Rounded - 120.5mm L x 120.5mm H | 31.00mm | 22.0 CFM (0.616m³/min) | 0.420 in H2O (104.6 Pa) | Ball | Blower | Auto Restart, Locked Rotor Protection | 42.0dB(A) | - | 2300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus | - |
|
|
ODB600AN-24MBThermal Products |
2,270 |
|
- |
|
ODB600AN | Bulk | Active | 24VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 27.0 CFM (0.756m³/min) | 0.420 in H2O (104.6 Pa) | Ball | Blower | Auto Restart | 41.8dB(A) | 7.2 W | 2175 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-24HBThermal Products |
4,500 |
|
- |
|
ODB600AN | Bulk | Active | 24VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 30.0 CFM (0.840m³/min) | 0.530 in H2O (132.0 Pa) | Ball | Blower | Auto Restart | 48.6dB(A) | 8.88 W | 2750 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-48MBThermal Products |
4,692 |
|
- |
|
ODB600AN | Bulk | Active | 48VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 27.0 CFM (0.756m³/min) | 0.420 in H2O (104.6 Pa) | Ball | Blower | Auto Restart | 41.8dB(A) | 5.76 W | 2175 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-48LBThermal Products |
4,962 |
|
- |
|
ODB600AN | Bulk | Active | 48VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 20.0 CFM (0.560m³/min) | 0.330 in H2O (82.2 Pa) | Ball | Blower | Auto Restart | 31.2dB(A) | 4.32 W | 1725 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-12MBThermal Products |
2,734 |
|
- |
|
ODB600AN | Bulk | Active | 12VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 27.0 CFM (0.756m³/min) | 0.420 in H2O (104.6 Pa) | Ball | Blower | Auto Restart | 41.8dB(A) | 5.64 W | 2175 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-12LBThermal Products |
2,783 |
|
- |
|
ODB600AN | Bulk | Active | 12VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 20.0 CFM (0.560m³/min) | 0.330 in H2O (82.2 Pa) | Ball | Blower | Auto Restart | 31.2dB(A) | 2.4 W | 1725 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-24LBThermal Products |
3,712 |
|
- |
|
ODB600AN | Bulk | Active | 24VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 20.0 CFM (0.560m³/min) | 0.330 in H2O (82.2 Pa) | Ball | Blower | Auto Restart | 31.2dB(A) | 4.8 W | 1725 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
ODB600AN-48HBThermal Products |
2,213 |
|
- |
|
ODB600AN | Bulk | Active | 48VDC | Rectangular/Rounded - 126mm L x 125mm H | 32.00mm | 30.0 CFM (0.840m³/min) | 0.530 in H2O (132.0 Pa) | Ball | Blower | Auto Restart | 48.6dB(A) | 7.2 W | 2750 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
DC0803824U2B-3T1FAN 80X38MM 24VDC TACH COMPUTER |
3,925 |
|
Datasheet |
|
- | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 38.00mm | 105.5 CFM (2.95m³/min) | 1.360 in H2O (338.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 62.0dB(A) | 36 W | 7500 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
9G1248M102FAN AXIAL 119X38MM 48VDC WIRE |
4,990 |
|
Datasheet |
|
San Ace 120 | Box | Active | 48VDC | Square - 119mm L x 119mm H | 38.00mm | 74.0 CFM (2.07m³/min) | 0.159 in H2O (39.6 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 32.0dB(A) | 3.36 W | 1950 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.728 lb (330.22 g) |
|
|
9G1248M1021FAN AXIAL 120X38MM 48VDC WIRE |
2,175 |
|
Datasheet |
|
San Ace 120 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 38.00mm | 74.0 CFM (2.07m³/min) | 0.159 in H2O (39.6 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 32.0dB(A) | 3.36 W | 1950 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.728 lb (330.22 g) |
|
GFB0812SHG-F00FAN AXIAL DUAL 80X50.8MM 12VDC |
2,901 |
|
Datasheet |
|
GFB | Box | Obsolete | 12VDC | Square - 80mm L x 80mm H | 50.80mm | 68.6 CFM (1.92m³/min) | 0.445 in H2O (110.8 Pa) | Ball | Tubeaxial (Dual) | Locked Rotor Protection, Speed Sensor (Tach) | 53.0dB(A) | 8.76 W | 4200 Front, 3750 Rear | 3 Wire Leads per Fan | - | 14 ~ 140°F (-10 ~ 60°C) | CE, CSA, UL, VDE | 0.364 lb (165.11 g) |
|
|
09238RA-48Q-EA-00FAN AXIAL 92X38MM 48VDC WIRE |
2,981 |
|
Datasheet |
|
09238RA | Bulk | Obsolete | 48VDC | Square - 92mm L x 92mm H | 38.00mm | 152.5 CFM (4.27m³/min) | 1.200 in H2O (298.9 Pa) | Ball | Tubeaxial | Auto Restart | 62.5dB | 27.4 W | 7200 RPM | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | - | - |
|
|
9GA0912P4G031FAN AXIAL 92X25MM 12VDC WIRE |
4,203 |
|
Datasheet |
|
San Ace 92 | Box | Active | 12VDC | Square - 92mm L x 92mm H | 25.00mm | 68.2 CFM (1.91m³/min) | 0.330 in H2O (82.2 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 39.0dB(A) | 3.36 W | 4400 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.276 lb (125.19 g) |
|
|
DC0803824L2B-3T1FAN 80X38MM 24VDC TACH COMPUTER |
4,071 |
|
Datasheet |
|
- | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 38.00mm | 58.2 CFM (1.63m³/min) | 0.410 in H2O (102.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 45.0dB(A) | 9.6 W | 4200 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
9L0412M302FAN AXIAL 40X28MM 12VDC WIRE |
2,746 |
|
Datasheet |
|
San Ace 40L | Box | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 5.7 CFM (0.160m³/min) | 0.096 in H2O (23.9 Pa) | Ball | Tubeaxial | - | 19.0dB(A) | 540 mW | 4000 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.122 lb (55.34 g) |
|
04028DA-12T-AK-H0FAN AXIAL 40X28MM 12VDC WIRE |
2,516 |
|
- |
|
04028DA | Bulk | Obsolete | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 36.0 CFM (1.01m³/min) | 4.260 in H2O (1061.2 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 66.5dB | 18.6 W | 26500 RPM | 4 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | - | 0.104 lb (47.17 g) |
|
|
9GL1248F1D01FAN AXIAL 120X38MM 48VDC WIRE |
2,341 |
|
Datasheet |
|
San Ace 120L | Box | Active | 48VDC | Square - 120mm L x 120mm H | 38.00mm | 87.0 CFM (2.44m³/min) | 0.218 in H2O (54.3 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 36.0dB(A) | 4.32 W | 2280 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | CSA, TUV, UL | 0.816 lb (370.13 g) |
