FETs, MOSFETs
| Manufacturer | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Reset All
Apply All
Result:
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SIE804DF-T1-GE3MOSFET N-CH 150V 37A 10POLARPAK Vishay Siliconix |
4,312 | - |
|
- |
 |
TrenchFET® | 10-PolarPAK® (LH) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 150 V | 37A (Tc) | 6V, 10V | 38mOhm @ 7.6A, 10V | 3V @ 250µA | 105 nC @ 10 V | ±20V | 3000 pF @ 50 V | - | 5.2W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 10-PolarPAK® (LH) |
|
SIE844DF-T1-GE3MOSFET N-CH 30V 44.5A 10POLARPAK Vishay Siliconix |
3,715 | - |
|
- |
|
TrenchFET® | 10-PolarPAK® (U) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 44.5A (Tc) | 4.5V, 10V | 7mOhm @ 12.1A, 10V | 3V @ 250µA | 44 nC @ 10 V | ±20V | 2150 pF @ 15 V | - | 5.2W (Ta), 25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 10-PolarPAK® (U) |
|
|
SIE848DF-T1-E3MOSFET N-CH 30V 60A 10POLARPAK Vishay Siliconix |
5,639 | - |
|
- |
|
TrenchFET® | 10-PolarPAK® (L) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 60A (Tc) | 4.5V, 10V | 1.6mOhm @ 25A, 10V | 2.5V @ 250µA | 138 nC @ 10 V | ±20V | 6100 pF @ 15 V | - | 5.2W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 10-PolarPAK® (L) |
|
|
SIE854DF-T1-E3MOSFET N-CH 100V 60A 10POLARPAK Vishay Siliconix |
5,046 | - |
|
Datasheet |
|
TrenchFET® | 10-PolarPAK® (L) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 60A (Tc) | 10V | 14.2mOhm @ 13.2A, 10V | 4.4V @ 250µA | 75 nC @ 10 V | ±20V | 3100 pF @ 50 V | - | 5.2W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 10-PolarPAK® (L) |
|
|
SIE876DF-T1-GE3MOSFET N-CH 60V 60A 10POLARPAK Vishay Siliconix |
5,317 | - |
|
- |
|
TrenchFET® | 10-PolarPAK® (L) | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 60A (Tc) | 10V | 6.1mOhm @ 20A, 10V | 4.4V @ 250µA | 77 nC @ 10 V | ±20V | 3100 pF @ 30 V | - | 5.2W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 10-PolarPAK® (L) |
|
SIHF8N50L-E3MOSFET N-CH 500V 8A TO220 Vishay Siliconix |
5,443 | - |
|
Datasheet |
|
- | TO-220-3 Full Pack | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 8A (Tc) | 10V | 1Ohm @ 4A, 10V | 5V @ 250µA | 34 nC @ 0 V | ±30V | 873 pF @ 25 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 Full Pack |
|
SIJ400DP-T1-GE3MOSFET N-CH 30V 32A PPAK SO-8 Vishay Siliconix |
5,265 | - |
|
- |
|
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 32A (Tc) | 4.5V, 10V | 4mOhm @ 20A, 10V | 2.5V @ 250µA | 150 nC @ 10 V | ±20V | 7765 pF @ 15 V | - | 5W (Ta), 69.4W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
|
SIJ484DP-T1-GE3MOSFET N-CH 30V 35A PPAK SO-8 Vishay Siliconix |
3,995 | - |
|
Datasheet |
|
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 35A (Tc) | 4.5V, 10V | 6.3mOhm @ 10A, 10V | 2.5V @ 250µA | 45 nC @ 10 V | ±20V | 1600 pF @ 15 V | - | 5W (Ta), 27.7W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
|
SIJ800DP-T1-GE3MOSFET N-CH 40V 20A PPAK SO-8 Vishay Siliconix |
4,182 | - |
|
- |
|
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 20A (Tc) | 4.5V, 10V | 9.5mOhm @ 20A, 10V | 3V @ 250µA | 56 nC @ 10 V | ±20V | 2400 pF @ 20 V | - | 4.2W (Ta), 35.7W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
SIR168DP-T1-GE3MOSFET N-CH 30V 40A PPAK SO-8 Vishay Siliconix |
5,927 | - |
|
- |
|
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 40A (Tc) | 4.5V, 10V | 4.4mOhm @ 15A, 10V | 2.4V @ 250µA | 75 nC @ 10 V | ±20V | 2040 pF @ 15 V | - | 5W (Ta), 34.7W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
