Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRR1210-471MFIXED IND 470UH 1.2A 820MOHM SMD |
140,580 |
|
Datasheet |
 |
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 470 µH | ±20% | 1.2 A | 1A | Shielded | 820mOhm Max | 12 @ 796kHz | 850kHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
SRP7030-100MFIXED IND 10UH 3A 0.085OHM SMD |
134,306 |
|
Datasheet |
|
SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 10 µH | ±20% | 3 A | 4.5A | Shielded | 85mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
|
SRR1210-150MFIXED IND 15UH 5.8A 32 MOHM SMD |
149,790 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 5.8 A | 5.3A | Shielded | 32mOhm Max | 16 @ 2.52MHz | 10.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
|
SRR1210-681MFIXED IND 680UH 1A 1.2 OHM SMD |
146,033 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 680 µH | ±20% | 1 A | 850mA | Shielded | 1.2Ohm Max | 11 @ 796kHz | 850kHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
SRP4020TA-150MFIXED IND 15UH 1.5A 374 MOHM SMD |
180,794 |
|
Datasheet |
|
SRP4020TA | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 15 µH | ±20% | 1.5 A | 1.9A | Shielded | 374mOhm Max | 10 @ 100kHz | 17MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | 2-SMD | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.079" (2.00mm) |
|
PA4342.822NLTFIXED IND 8.2UH 8A 25.5 MOHM SMD |
165,870 |
|
Datasheet |
|
PA4342.XXXNLT | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 8.2 µH | ±20% | 8 A | 12.5A | Shielded | 25.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.453" L x 0.406" W (11.50mm x 10.30mm) | 0.157" (4.00mm) |
|
CDRH124NP-680MCFIXED IND 68UH 1.5A 220 MOHM SMD |
186,969 |
|
Datasheet |
|
CDRH124 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 68 µH | ±20% | 1.5 A | - | Shielded | 220mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.177" (4.50mm) |
|
CDRH125NP-151MCFIXED IND 150UH 1A 230 MOHM SMD |
137,233 |
|
Datasheet |
|
CDRH125 | Nonstandard | Tape & Reel (TR) | Active | - | - | 150 µH | ±20% | 1 A | - | Shielded | 230mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.236" (6.00mm) |
|
|
SRR1210-221MFIXED IND 220UH 1.7A 315MOHM SMD |
125,260 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±20% | 1.7 A | 1.5A | Shielded | 315mOhm Max | 15 @ 796kHz | 1.8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
|
SRP7030-4R7MFIXED IND 4.7UH 5.5A 0.04OHM SMD |
114,600 |
|
Datasheet |
|
SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 4.7 µH | ±20% | 5.5 A | 6.5A | Shielded | 40mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
SRP4012TA-1R5MFIXED IND 1.5UH 3A 56 MOHM SMD |
197,222 |
|
Datasheet |
|
SRP4012TA | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 1.5 µH | ±20% | 3 A | 4A | Shielded | 56mOhm Max | 10 @ 100kHz | 62MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | 2-SMD | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
SRR1210-220MFIXED IND 22UH 5.2A 38 MOHM SMD |
142,305 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 5.2 A | 4.5A | Shielded | 38mOhm Max | 16 @ 2.52MHz | 8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
|
SRR1210-100MFIXED IND 10UH 6.5A 18 MOHM SMD |
119,863 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 6.5 A | 6.5A | Shielded | 18mOhm Max | 16 @ 2.52MHz | 12MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
|
SRP7030-R47MFIXED IND 470NH 17.5A 0.0042OHM |
172,398 |
|
Datasheet |
|
SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 470 nH | ±20% | 17.5 A | 26A | Shielded | 4.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
|
CDRH124NP-330MCFIXED IND 33UH 2.7A 97 MOHM SMD |
102,402 |
|
Datasheet |
|
CDRH124 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 33 µH | ±20% | 2.7 A | - | Shielded | 97mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.177" (4.50mm) |
|
|
SRR1210-390MFIXED IND 39UH 4.2A 66 MOHM SMD |
194,820 |
|
Datasheet |
|
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 39 µH | ±20% | 4.2 A | 3.5A | Shielded | 66mOhm Max | 16 @ 2.52MHz | 4.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.394" (10.00mm) |
|
|
SRP4020TA-1R2MFIXED IND 1.2UH 4.8A 30 MOHM SMD |
166,890 |
|
Datasheet |
|
SRP4020TA | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 1.2 µH | ±20% | 4.8 A | 7.8A | Shielded | 30mOhm Max | 10 @ 100kHz | 64MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | 2-SMD | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.079" (2.00mm) |
|
|
SRP7030-3R3MFIXED IND 3.3UH 6A 0.03OHM SMD |
149,989 |
|
Datasheet |
|
SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 3.3 µH | ±20% | 6 A | 10A | Shielded | 30mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
|
SRP7030-6R8MFIXED IND 6.8UH 4.5A 0.06OHM SMD |
149,276 |
|
Datasheet |
|
SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 6.8 µH | ±20% | 4.5 A | 6A | Shielded | 60mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
74479889310WE-PMI SMT POWER INDUCTOR SIZE 1 |
196,415 |
|
Datasheet |
|
WE-PMI | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Multilayer | Nickel Zinc Ferrite (NiZn) | 10 µH | ±20% | 800 mA | 500mA | Shielded | 625mOhm Max | 15 @ 1MHz | 20MHz | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.047" (1.20mm) |
