Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSS1048-103MLCFIXED IND 10UH 4.79A 23MOHM SM Coilcraft |
118,722 |
|
Datasheet |
 |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 10 µH | ±20% | 4.79 A | 3.08A | Shielded | 23mOhm Max | - | 24MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-104MLCFIXED IND 100UH 1.48A 224MOHM SM Coilcraft |
198,626 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 100 µH | ±20% | 1.48 A | 990mA | Shielded | 224mOhm Max | - | 6MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-153MLCFIXED IND 15UH 4.26A 36MOHM SM Coilcraft |
136,960 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 15 µH | ±20% | 4.26 A | 2.46A | Shielded | 36mOhm Max | - | 20MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-822NLCFIXED IND 8.2UH 5.71A 20MOHM SM Coilcraft |
188,926 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 8.2 µH | ±30% | 5.71 A | 3.14A | Shielded | 20mOhm Max | - | 28MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-472NLCFIXED IND 4.7UH 6.9A 11.5MOHM SM Coilcraft |
133,746 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 4.7 µH | ±30% | 6.9 A | 4.36A | Shielded | 11.5mOhm Max | - | 38MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-683MLCFIXED IND 68UH 1.88A 176MOHM SM Coilcraft |
101,956 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 68 µH | ±20% | 1.88 A | 1.28A | Shielded | 176mOhm Max | - | 7MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-682NLCFIXED IND 6.8UH 6.01A 16.3MOHM Coilcraft |
108,544 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 6.8 µH | ±30% | 6.01 A | 3.6A | Shielded | 16.3mOhm Max | - | 35MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-222NLCFIXED IND 2.2UH 9.78A 7.2MOHM SM Coilcraft |
136,849 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 2.2 µH | ±30% | 9.78 A | 4.92A | Shielded | 7.2mOhm Max | - | 70MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-224KLCFIXED IND 220UH 1.18A 394MOHM SM Coilcraft |
158,616 |
|
Datasheet |
|
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 220 µH | ±10% | 1.18 A | 670mA | Shielded | 394mOhm Max | - | 4.5MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
XGL4040-332MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
182,530 |
|
Datasheet |
|
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 3.3 µH | ±20% | 8.7 A | 5.5A | Shielded | 16.6mOhm Max | - | 32MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
