Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSS6132-123MLCPOWER INDUCTOR, SHIELDED, 20% TO Coilcraft |
173,327 |
|
Datasheet |
 |
MSS6132 | Nonstandard | Strip | Active | Drum Core | Ferrite | 12 µH | ±20% | 1.75 A | 1.3A | Shielded | 79mOhm Max | - | 33MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.240" W (6.10mm x 6.10mm) | 0.126" (3.20mm) |
|
0402CS-18NXGRWFIXED IND 18NH 420MA 230MOHM SM Coilcraft |
132,610 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 18 nH | ±2% | 420 mA | - | Unshielded | 230mOhm Max | 57 @ 900MHz | 3.1GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-3N3XGRWFIXED IND 3.3NH 840MA 66MOHM SM Coilcraft |
188,012 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 3.3 nH | ±2% | 840 mA | - | Unshielded | 66mOhm Max | 65 @ 900MHz | 7GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-8N2XGRWFIXED IND 8.2NH 680MA 100MOHM SM Coilcraft |
142,229 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 8.2 nH | ±2% | 680 mA | - | Unshielded | 100mOhm Max | 57 @ 900MHz | 4.4GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-56NXGRWFIXED IND 56NH 100MA 970MOHM SM Coilcraft |
147,110 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 56 nH | ±2% | 100 mA | - | Unshielded | 970mOhm Max | 42 @ 900MHz | 1.76GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-6N8XGRWFIXED IND 6.8NH 680MA 83MOHM SM Coilcraft |
108,862 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 6.8 nH | ±2% | 680 mA | - | Unshielded | 83mOhm Max | 63 @ 900MHz | 4.8GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-20NXGRWFIXED IND 20NH 420MA 250MOHM SM Coilcraft |
102,983 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 20 nH | ±2% | 420 mA | - | Unshielded | 250mOhm Max | 52 @ 900MHz | 3GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-13NXGRWFIXED IND 13NH 440MA 210MOHM SM Coilcraft |
188,328 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 13 nH | ±2% | 440 mA | - | Unshielded | 210mOhm Max | 51 @ 900MHz | 3.45GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-2N0XGRWFIXED IND 2NH 1.04A 70MOHM SM Coilcraft |
132,687 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 2 nH | ±2% | 1.04 A | - | Unshielded | 70mOhm Max | 54 @ 900MHz | 11.1GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
|
|
0402CS-8N7XGRWFIXED IND 8.7NH 480MA 200MOHM SM Coilcraft |
198,454 |
|
Datasheet |
|
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 8.7 nH | ±2% | 480 mA | - | Unshielded | 200mOhm Max | 54 @ 900MHz | 4.1GHz | AEC-Q200 | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | 0.026" (0.66mm) |
