Isolators - Gate Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | Technology | Number of Channels | Voltage - Isolation | Common Mode Transient Immunity (Min) | Propagation Delay tpLH / tpHL (Max) | Pulse Width Distortion (Max) | Rise / Fall Time (Typ) | Current - Output High, Low | Current - Peak Output | Voltage - Forward (Vf) (Typ) | Current - DC Forward (If) (Max) | Voltage - Output Supply | Grade | Qualification | Operating Temperature | Mounting Type | Supplier Device Package | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP5771(D4-TP,EOPTOISO 5KV 1CH GATE DVR 6SO Toshiba Semiconductor and Storage |
4,778 |
|
Datasheet |
 |
- | 6-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 5000Vrms | 35kV/µs | 150ns, 150ns | 50ns | 15ns, 8ns | 1A, 1A | 1A | 1.65V | 8 mA | 10V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 6-SO | CQC, cUR, UR, VDE |
|
TLP5774H(D4-TP,EOPTOISO 5KV 1CH GATE DVR 6SO Toshiba Semiconductor and Storage |
5,370 |
|
Datasheet |
|
- | 6-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 5000Vrms | 35kV/µs | 150ns, 150ns | 50ns | 56ns, 25ns | 4A, 4A | 4A | 1.65V | 8 mA | 10V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SO | CQC, CSA, cUL, UL, VDE |
.jpg)
|
TLP701H(F)OPTOISO 5KV 1CH GATE DVR 6SDIP Toshiba Semiconductor and Storage |
3,419 |
|
Datasheet |
|
- | 6-SOIC (0.268", 6.80mm Width) | Tube | Obsolete | Optical Coupling | 1 | 5000Vrms | 20kV/µs | 700ns, 700ns | 500ns | 50ns, 50ns | 400mA, 400mA | 600mA | 1.57V | 25 mA | 10V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SDIP Gull Wing | cUL, UL |
|
|
TLP700H(F)OPTOISO 5KV 1CH GATE DVR 6SDIP Toshiba Semiconductor and Storage |
4,379 |
|
Datasheet |
|
- | 6-SOIC (0.268", 6.80mm Width) | Tube | Obsolete | Optical Coupling | 1 | 5000Vrms | 20kV/µs | 500ns, 500ns | 250ns | 15ns, 8ns | 2A, 2A | 2.5A | 1.55V | 20 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 6-SDIP | cUL, UL |
|
|
TLP5774(D4-TP,EOPTOISO 5KV 1CH GATE DVR 6SO Toshiba Semiconductor and Storage |
5,599 |
|
Datasheet |
|
- | 6-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 5000Vrms | 35kV/µs | 150ns, 150ns | 50ns | 15ns, 8ns | 1.2A, 1.2A | 4A | 1.65V | 8 mA | 10V ~ 30V | - | - | -40°C ~ 110°C | Surface Mount | 6-SO | CQC, cUR, UR, VDE |
|
TLP352(LF1,F)OPTOISO 3.75KV 1CH GATE DVR 8SMD Toshiba Semiconductor and Storage |
5,104 |
|
Datasheet |
|
- | 8-SMD, Gull Wing | Tube | Active | Optical Coupling | 1 | 3750Vrms | 20kV/µs | 200ns, 200ns | 50ns | 15ns, 8ns | 2A, 2A | 2.5A | 1.55V | 20 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 8-SMD | CSA, cUL, UL |
|
TLP358H(TP1,F)OPTOISO 3.75KV 1CH GATE DVR 8SMD Toshiba Semiconductor and Storage |
4,847 |
|
- |
|
- | 8-SMD, Gull Wing | Tape & Reel (TR) | Discontinued at Digi-Key | Optical Coupling | 1 | 3750Vrms | 20kV/µs | 500ns, 500ns | 250ns | 17ns, 17ns | 5A, 5A | 6A | 1.57V | 20 mA | 15V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 8-SMD | cUL, UL |
|
TLP2451A(TP,F)OPTOISO 3.75KV 1CH GATE DVR 8SO Toshiba Semiconductor and Storage |
4,203 |
|
- |
|
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Optical Coupling | 1 | 3750Vrms | 20kV/µs | 500ns, 500ns | 350ns | 50ns, 50ns | 400mA, 400mA | 600mA | 1.55V | 25 mA | 10V ~ 30V | - | - | -40°C ~ 125°C | Surface Mount | 8-SO | CSA, cUL, UL |
|
|
TLP250(TP1,F)OPTOISO 2.5KV 1CH GATE DVR 8SMD Toshiba Semiconductor and Storage |
5,244 |
|
- |
|
- | 8-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | Optical Coupling | 1 | 2500Vrms | 5kV/µs | 500ns, 500ns | - | - | 500mA, 500mA | 1.5A | 1.6V | 20 mA | 15V ~ 30V | - | - | -20°C ~ 85°C | Surface Mount | 8-SMD | UR |
|
|
TLP701(TP,F)OPTOISO 5KV 1CH GATE DVR 6SDIP Toshiba Semiconductor and Storage |
5,481 |
|
- |
|
- | 6-SOIC (0.268", 6.80mm Width) | Tape & Reel (TR) | Obsolete | Optical Coupling | 1 | 5000Vrms | 10kV/µs | 700ns, 700ns | - | 50ns, 50ns | 400mA, 400mA | 600mA | 1.55V | 20 mA | 10V ~ 30V | - | - | -40°C ~ 100°C | Surface Mount | 6-SDIP Gull Wing | cUL, UL |
