Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
953 204SPD TYPE 3 150VAC/150VDC MCOV |
5,026 |
|
Datasheet |
 |
DEHNrail M | Bulk | Active | Type 3 | Base + Module | 2 | 150VAC, 150VDC | 2 kA | 4 kA | - | 640 V | 800 V | -40°C ~ 80°C | - | DIN Rail | ATEX, CSA, IECEx, KEMA, UL, VDE |
|
|
953 011SPD 30VAC/30VDC MCOV |
3,391 |
|
Datasheet |
|
DEHNrail M | Bulk | Active | - | Module Only | - | 30VAC, 30VDC | 1 kA | 2 kA | - | - | - | -40°C ~ 80°C | - | - | CE, UKCA |
|
|
927 244SPD TYPE 1 36VDC/25.4VAC MCOV |
4,877 |
|
Datasheet |
|
Blitzductorconnect Modular | Bulk | Active | Type 1 | Base + Module | 2 | 36VDC, 25.4VAC | 5 kA | 10 kA | - | 57 V | 600 V | -40°C ~ 80°C | LifeCheck Arrester Monitoring | DIN Rail | ATEX, CCC, CSA, IECEx, SIL, UL497B |
|
|
953 205SPD TYPE 3 255VAC/255VDC MCOV |
5,209 |
|
Datasheet |
|
DEHNrail M | Bulk | Active | Type 3 | Base + Module | 2 | 255VAC, 255VDC | 3 kA | 5 kA | - | 1.25 kV | 1.5 kV | -40°C ~ 80°C | - | DIN Rail | ATEX, CSA, IECEx, KEMA, UL, VDE |
|
|
908 195SPD TYPE 1 230VAC/460VAC MCOV |
5,417 |
|
Datasheet |
|
DEHNguard M | Bulk | Active | Type 1 | Base + Module | 2 | 230VAC, 460VAC | 20 kA | 50 kA | - | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | CSA, UL |
|
|
920 344SPD TYPE 1 33VDC/23.3VAC MCOV |
5,456 |
|
Datasheet |
|
Blitzductor XT | Bulk | Active | Type 1 | Module Only | - | 33VDC, 23.3VAC | 10 kA | 20 kA | - | - | 550 V | -40°C ~ 80°C | LifeCheck | - | ATEX, CCC, CSA, CSA & USA Hazloc, IECEx, UL497B |
|
|
953 209SPD TYPE 3 150VAC/150VDC MCOV |
5,027 |
|
Datasheet |
|
DEHNrail M | Bulk | Active | Type 3 | Base + Module | 2 | 150VAC, 150VDC | 2 kA | 4 kA | - | 640 V | 800 V | -40°C ~ 80°C | - | DIN Rail | ATEX, CSA, IECEx, KEMA, UL, VDE |
|
|
952 090SPD TYPE 2 275VAC/350VDC MCOV |
5,767 |
|
Datasheet |
|
DEHNguard S | Bulk | Active | Type 2 | Base + Module | 1 | 275VAC, 350VDC | 20 kA | 40 kA | - | 1.5 kV | 1 kV | -40°C ~ 80°C | - | DIN Rail | CSA, KEMA, UL, VDE |
|
|
908 345SPD TYPE 1 180/360VAC MCOV 3POLE |
4,755 |
|
Datasheet |
|
DEHNguard M | Bulk | Active | Type 1 | Base + Module | 3 | 180VAC, 360VAC, 360VAC, 180VAC | 20 kA | 50 kA | - | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | CSA, UL |
|
|
908 190SPD TYPE 1 230VAC/460VAC MCOV |
3,473 |
|
Datasheet |
|
DEHNguard M | Bulk | Active | Type 1 | Base + Module | 2 | 230VAC, 460VAC | 20 kA | 50 kA | - | - | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | CSA, UL |
|
|
929 921SPD TYPE 2 34.8VDC/24.5VAC MCOV |
3,101 |
|
Datasheet |
|
DEHNpipe | Bulk | Active | Type 2 | - | - | 34.8VDC, 24.5VAC | 10 kA | 10 kA | - | 65 V | 120 V | -40°C ~ 80°C | 1/2-14 NPT Mounting | - | CE, SIL, UL |
|
AHW120-80SPD TYPE 2/TYPE 4 150VAC MCOV |
5,090 |
|
Datasheet |
|
- | Box | Active | Type 2, Type 4 | - | 1 | 150VAC | 20 kA | 80 kA | 65 kA | - | - | -40°C ~ 85°C | Visual Life Indicator | Wall Mount | - |
|
2730610000SPD SURGE PRO MD 350V MCOV 4POLE |
4,142 |
|
Datasheet |
|
VPU | Bulk | Active | Surge Protection Module | Base + Module | 4 | 350V | 40 kA | 50 kA | 200 kA | 2 kV | 1.75 kV | -40°C ~ 85°C | - | DIN Rail | cULus, VDE |
|
AP5P277LSPD 320V MCOV 1 POLE |
5,441 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 320V | 5 kA | 10 kA | - | - | - | -40°C ~ 70°C | Thermally Protected | Chassis Mount | cURus |
|
AP10S480LHSPD 550V MCOV 1 POLE |
5,779 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 550V | 10 kA | 25 kA | - | - | - | -40°C ~ 70°C | Thermally Protected, Visual Life Indicator | Chassis Mount | cURus |
|
AP10P480LHSPD 550V MCOV 1 POLE |
3,570 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 550V | 10 kA | 25 kA | - | - | - | -40°C ~ 70°C | Thermally Protected, Visual Life Indicator | Chassis Mount | cURus |
|
AP5P480SPD 550V MCOV 1 POLE |
3,517 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 550V | 5 kA | 10 kA | - | - | - | -40°C ~ 70°C | Thermally Protected | Free Hanging | cURus |
|
AP5S277LSPD 320V MCOV 1 POLE |
3,876 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 320V | 5 kA | 10 kA | - | - | - | -40°C ~ 70°C | Thermally Protected | Chassis Mount | cURus |
|
AP10P480GHSPD 550V MCOV 1 POLE |
5,829 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 550V | 10 kA | 25 kA | - | - | - | -40°C ~ 70°C | Thermally Protected, Visual Life Indicator | Chassis Mount | cURus |
|
AP10S480GHSPD 550V MCOV 1 POLE |
5,512 |
|
Datasheet |
|
Hardwired | Box | Active | - | Module Only | 1 | 550V | 10 kA | 25 kA | - | - | - | -40°C ~ 70°C | Thermally Protected, Visual Life Indicator | Chassis Mount | cURus |
