DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1204KL-01W-B39-B50FAN AXIAL 30X10MM BALL 5VDC WIRE |
4,796 |
|
Datasheet |
 |
1204KL | Box | Obsolete | 5VDC | Square - 30mm L x 30mm H | 10.00mm | 2.7 CFM (0.076m³/min) | 0.116 in H2O (29.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 21.0dB | 500 mW | 7500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-01W-B49-B00FAN AXIAL 30X10MM BALL 5VDC WIRE |
2,664 |
|
Datasheet |
|
1204KL | Box | Obsolete | 5VDC | Square - 30mm L x 30mm H | 10.00mm | 3.2 CFM (0.090m³/min) | 0.148 in H2O (37.0 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 23.0dB | 700 mW | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-01W-B49-B50FAN AXIAL 30X10MM BALL 5VDC WIRE |
2,930 |
|
Datasheet |
|
1204KL | Box | Obsolete | 5VDC | Square - 30mm L x 30mm H | 10.00mm | 3.2 CFM (0.090m³/min) | 0.148 in H2O (37.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 23.0dB | 700 mW | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-01W-B59-B50FAN AXIAL 30X10MM BALL 5VDC WIRE |
4,658 |
|
Datasheet |
|
1204KL | Box | Obsolete | 5VDC | Square - 30mm L x 30mm H | 10.00mm | 3.8 CFM (0.106m³/min) | 0.216 in H2O (53.8 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 27.0dB | 900 mW | 10500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-04W-B39-B00FAN AXIAL 30X10MM 12VDC WIRE |
3,504 |
|
Datasheet |
|
1204KL | Box | Obsolete | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 2.7 CFM (0.076m³/min) | 0.116 in H2O (29.0 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 21.0dB | 720 mW | 7500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-04W-B39-B50FAN AXIAL 30X10MM 12VDC WIRE |
4,541 |
|
Datasheet |
|
1204KL | Box | Obsolete | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 2.7 CFM (0.076m³/min) | 0.116 in H2O (29.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 21.0dB | 720 mW | 7500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-04W-B49-B00FAN AXIAL 30X10MM 12VDC WIRE |
4,197 |
|
Datasheet |
|
1204KL | Box | Obsolete | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 3.2 CFM (0.090m³/min) | 0.148 in H2O (37.0 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 23.0dB | 840 mW | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-04W-B49-B50FAN AXIAL 30X10MM 12VDC WIRE |
2,362 |
|
Datasheet |
|
1204KL | Box | Obsolete | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 3.2 CFM (0.090m³/min) | 0.148 in H2O (37.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 23.0dB | 840 mW | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1204KL-04W-B59-B50FAN AXIAL 30X10MM 12VDC WIRE |
3,218 |
|
Datasheet |
|
1204KL | Box | Obsolete | 12VDC | Square - 30mm L x 30mm H | 10.00mm | 3.8 CFM (0.106m³/min) | 0.216 in H2O (53.8 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 27.0dB | 960 mW | 10500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.019 lb (8.62 g) |
|
|
1404KL-01W-B39-B00FAN AXIAL 35X10MM BALL 5VDC WIRE |
4,003 |
|
Datasheet |
|
1404KL | Box | Obsolete | 5VDC | Square - 35mm L x 35mm H | 10.00mm | 3.0 CFM (0.084m³/min) | 0.062 in H2O (15.4 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 19.0dB | 400 mW | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-01W-B39-B50FAN AXIAL 35X10MM BALL 5VDC WIRE |
2,363 |
|
Datasheet |
|
1404KL | Box | Obsolete | 5VDC | Square - 35mm L x 35mm H | 10.00mm | 3.0 CFM (0.084m³/min) | 0.062 in H2O (15.4 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 19.0dB | 400 mW | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-01W-B49-B00FAN AXIAL 35X10MM BALL 5VDC WIRE |
3,803 |
|
Datasheet |
|
1404KL | Box | Obsolete | 5VDC | Square - 35mm L x 35mm H | 10.00mm | 4.2 CFM (0.118m³/min) | 0.107 in H2O (26.6 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 22.0dB | 850 mW | 7000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-01W-B49-B50FAN AXIAL 35X10MM BALL 5VDC WIRE |
3,930 |
|
Datasheet |
|
1404KL | Box | Obsolete | 5VDC | Square - 35mm L x 35mm H | 10.00mm | 4.2 CFM (0.118m³/min) | 0.107 in H2O (26.6 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 22.0dB | 850 mW | 7000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-01W-B59-B00FAN AXIAL 35X10MM BALL 5VDC WIRE |
3,239 |
|
Datasheet |
|
1404KL | Box | Obsolete | 5VDC | Square - 35mm L x 35mm H | 10.00mm | 5.6 CFM (0.157m³/min) | 0.165 in H2O (41.1 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 27.0dB | 1.05 W | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-04W-B39-B00FAN AXIAL 35X10MM 12VDC WIRE |
2,406 |
|
Datasheet |
|
1404KL | Box | Obsolete | 12VDC | Square - 35mm L x 35mm H | 10.00mm | 3.0 CFM (0.084m³/min) | 0.062 in H2O (15.4 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 19.0dB | 480 mW | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-04W-B39-B50FAN AXIAL 35X10MM 12VDC WIRE |
3,311 |
|
Datasheet |
|
1404KL | Box | Obsolete | 12VDC | Square - 35mm L x 35mm H | 10.00mm | 3.0 CFM (0.084m³/min) | 0.062 in H2O (15.4 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 19.0dB | 480 mW | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-04W-B49-B00FAN AXIAL 35X10MM 12VDC WIRE |
4,336 |
|
Datasheet |
|
1404KL | Box | Obsolete | 12VDC | Square - 35mm L x 35mm H | 10.00mm | 4.2 CFM (0.118m³/min) | 0.107 in H2O (26.6 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 22.0dB | 840 mW | 7000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-04W-B49-B50FAN AXIAL 35X10MM 12VDC WIRE |
3,749 |
|
Datasheet |
|
1404KL | Box | Obsolete | 12VDC | Square - 35mm L x 35mm H | 10.00mm | 4.2 CFM (0.118m³/min) | 0.107 in H2O (26.6 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 22.0dB | 840 mW | 7000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
|
1404KL-04W-B59-B50FAN AXIAL 35X10MM 12VDC WIRE |
3,737 |
|
Datasheet |
|
1404KL | Box | Obsolete | 12VDC | Square - 35mm L x 35mm H | 10.00mm | 5.6 CFM (0.157m³/min) | 0.165 in H2O (41.1 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 27.0dB | 960 mW | 9000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.026 lb (11.79 g) |
|
1604KL-01W-B39-B00FAN AXIAL 40X10MM BALL 5VDC WIRE |
2,437 |
|
Datasheet |
|
04010KA | Box | Obsolete | 5VDC | Square - 40mm L x 40mm H | 10.00mm | 4.2 CFM (0.118m³/min) | 0.096 in H2O (23.9 Pa) | Ball | Tubeaxial | Locked Rotor Sensor | 22.0dB | 375 mW | 4500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.033 lb (14.97 g) |
