Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | RoHs | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DR74-102-RFIXED IND 1MH 270MA 3.89 OHM SMD |
141,536 |
|
Datasheet |
 |
DR | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1 mH | ±20% | 270 mA | 310mA | Shielded | 3.89Ohm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.299" L x 0.299" W (7.60mm x 7.60mm) | 0.171" (4.35mm) |
|
L0603100GGSTRFIXED IND 10NH 300MA 450MOHM SMD |
174,098 |
|
- |
|
Accu-L® | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | 10 nH | ±2% | 300 mA | - | Unshielded | 450mOhm Max | 28 @ 450MHz | 3.5GHz | - | -55°C ~ 125°C | 450 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.032" W (1.60mm x 0.81mm) | 0.028" (0.71mm) |
|
SRR4028-390YFIXED IND 39UH 800MA 250MOHM SMD |
145,877 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 39 µH | ±30% | 800 mA | 500mA | Shielded | 250mOhm Max | 9.74 @ 2.52MHz | 14MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
ASPI-0530LR-4R7M-T2FIXED IND 4.7UH 4.5A 60 MOHM SMD |
107,093 |
|
Datasheet |
|
ASPI-0530LR | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 4.7 µH | ±20% | 4.5 A | 4.5A | Shielded | 60mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.220" L x 0.205" W (5.60mm x 5.20mm) | 0.118" (3.00mm) |
|
|
SRR4028-470YFIXED IND 47UH 750MA 280MOHM SMD |
197,835 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±30% | 750 mA | 480mA | Shielded | 280mOhm Max | 10.88 @ 2.52MHz | 13MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
SLF6045T-100M1R6-3PFFIXED IND 10UH 2.7A 46.8MOHM SMD |
167,895 |
|
Datasheet |
|
SLF | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 2.7 A | 1.6A | Shielded | 46.8mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.189" (4.80mm) |
|
|
SRR4028-121YFIXED IND 120UH 470MA 700MOHM SM |
145,970 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 120 µH | ±30% | 470 mA | 280mA | Shielded | 700mOhm Max | 13.32 @ 796kHz | 8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
L0603150GGSTRFIXED IND 15NH 300MA 600MOHM SMD |
126,165 |
|
Datasheet |
|
Accu-L® | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | 15 nH | ±2% | 300 mA | - | Unshielded | 600mOhm Max | 28 @ 450MHz | 2.5GHz | - | -55°C ~ 125°C | 450 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.032" W (1.60mm x 0.81mm) | 0.028" (0.71mm) |
|
|
SRR4028-220YFIXED IND 22UH 930MA 185MOHM SMD |
192,918 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±30% | 930 mA | 720mA | Shielded | 185mOhm Max | 8.26 @ 2.52MHz | 23MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
ASPI-0315FS-100M-T2FIXED IND 10UH 1.1A 220 MOHM SMD |
186,090 |
|
Datasheet |
|
ASPI-0315FS | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 770 mA | 720mA | Shielded | 325mOhm Max | - | 41MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | - | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.059" (1.50mm) |
|
|
SRR4028-820YFIXED IND 82UH 560MA 520MOHM SMD |
151,696 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 82 µH | ±30% | 560 mA | 320mA | Shielded | 520mOhm Max | 8.6 @ 2.52MHz | 8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
SRR4028-3R9YFIXED IND 3.9UH 1.72A 60MOHM SMD |
100,213 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.9 µH | ±30% | 1.72 A | 1.5A | Shielded | 60mOhm Max | 8.58 @ 7.96MHz | 56MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
SRR4028-150YFIXED IND 15UH 1.03A 150MOHM SMD |
145,978 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±30% | 1.03 A | 780mA | Shielded | 150mOhm Max | 9.66 @ 2.52MHz | 27MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
SRR4028-1R8YFIXED IND 1.8UH 2.7A 25 MOHM SMD |
129,248 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.8 µH | ±30% | 2.7 A | 2.2A | Shielded | 25mOhm Max | 9.18 @ 7.96MHz | 146MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
1227AS-H-4R7M=P2FIXED IND 4.7UH 1.8A 92 MOHM SMD |
108,308 |
|
Datasheet |
|
- | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 1.8 A | 1.1A | Shielded | 92mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.126" L x 0.118" W (3.20mm x 3.00mm) | 0.071" (1.80mm) |
|
|
1227AS-H-120M=P2FIXED IND 12UH 1A 258 MOHM SMD |
153,798 |
|
Datasheet |
|
- | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 12 µH | ±20% | 1 A | 650mA | Shielded | 258mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.126" L x 0.118" W (3.20mm x 3.00mm) | 0.071" (1.80mm) |
|
|
1227AS-H-3R3M=P2FIXED IND 3.3UH 2A 67 MOHM SMD |
144,065 |
|
Datasheet |
|
- | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 2 A | 1.3A | Shielded | 67mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.126" L x 0.118" W (3.20mm x 3.00mm) | 0.071" (1.80mm) |
|
|
SRR4028-6R8YFIXED IND 6.8UH 1.3A 90 MOHM SMD |
158,933 |
|
Datasheet |
|
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 1.3 A | 1.15A | Shielded | 90mOhm Max | 9.624 @ 7.96MHz | 77MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.118" (3.00mm) |
|
|
SLF6045T-220M1R1-3PFFIXED IND 22UH 1.8A 98.4MOHM SMD |
162,467 |
|
Datasheet |
|
SLF | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 1.8 A | 1.1A | Shielded | 98.4mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.189" (4.80mm) |
|
ASPI-8040S-331M-TFIXED IND 330UH 640MA 889MOHM SM |
135,537 |
|
Datasheet |
|
ASPI-8040S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±20% | 640 mA | 680mA | Shielded | 889mOhm | - | 2.8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.157" (4.00mm) |
