    Microchip Technology SG2023J

    Part No.:
    SG2023J
    Manufacturer:
    Microchip Technology
    Category:
    Bipolar Transistor Arrays
    Package:
    16-CDIP (0.300", 7.62mm)
    Datasheet:
    SENICO ELECTRONICS INTL CO., LIMITEDSG2023J.pdf
    Description:
    TRANS 7NPN DARL 95V 16CERDIP
    Quantity:

    Unit Price:$0

    Ext Price:$0

    Payment:
    Payment
    Shipping:
    Shipping

    Inventory:4,804

    Send us your inquiry,we will respond immediately.

    Part Number
    Quantity
    Price
    Name
    Company
    Email
    Comments

    In Stock:4,804

    Qty. Unit Price Ext. Price
    RFQ now Add to cart

    Product details

    • Specifications
    • FAQ
    • Comparison
    Attributes
    Property Value
    Manufacturer:
    Microchip Technology
    Series:
    -
    Package/Case:
    16-CDIP (0.300", 7.62mm)
    Packaging:
    Tray
    Product Status:
    Active
    Transistor Type:
    7 NPN Darlington
    Current - Collector (Ic) (Max):
    500mA
    Voltage - Collector Emitter Breakdown (Max):
    95V
    Vce Saturation (Max) @ Ib, Ic:
    1.6V @ 500µA, 350mA
    Current - Collector Cutoff (Max):
    -
    DC Current Gain (hFE) (Min) @ Ic, Vce:
    1000 @ 350mA, 2V
    Power - Max:
    -
    Frequency - Transition:
    -
    Operating Temperature:
    -55°C ~ 125°C (TA)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Through Hole
    Supplier Device Package:
    16-CERDIP
    Category:
    Bipolar Transistor Arrays
