Nidec Components Corporation CHS-01TB

SWITCH SLIDE DIP SPST 0.1A 6V

Answer first: this page is a purchasing reference for the exact part number CHS-01TB from Nidec Components Corporation. Use it to start datasheet, package, manufacturer and RFQ verification; do not treat page text as a live stock, price or lead-time promise.

Manufacturer: Nidec Components Corporation Category: DIP Switches Part number: CHS-01TB Package: RFQ verification required

Key Parameters

Part NumberCHS-01TB
ManufacturerNidec Components Corporation
CategoryDIP Switches
seriesCHS
packagingTape & Reel (TR)
product statusActive
param 1SPST
param 21
param 3100mA
param 46VDC
param 5Slide (Standard)
param 6Flush, Recessed
param 7Copper Alloy
param 8Gold
param 90.098" (2.50mm)
param 10Surface Mount
param 11Gull Wing
param 120.050" (1.27mm), Half
param 13Yes
param 14Tape Seal
param 15-40°C ~ 85°C

Parameters are provided for purchasing review. Confirm package, suffix, lifecycle status, datasheet revision and approved substitutes before ordering.

How to Verify CHS-01TB Before Ordering

Datasheet and parameter checks

  • Confirm the full manufacturer part number, not only a shortened search keyword.
  • Compare package, pinout, dimensions, voltage or rating fields, temperature range and compliance wording against the released BOM.
  • Use the manufacturer datasheet or drawing for electrical and mechanical limits before approving a substitute.

RFQ fields SENICO needs

  • Send exact part number, manufacturer, quantity, target delivery date, destination and required packaging.
  • State whether alternates are allowed, and list any date-code, certificate, traceability or customer AVL requirement.
  • Keep exact stock, factory lead time and proposed alternatives in separate quote lanes.

For CHS-01TB, SENICO recommends checking manufacturer marking, package, date code, requested quantity, approved vendor requirements and replacement risk before issuing a purchase order. If a supplier suggests an equivalent, record the changed fields and approval owner before comparing price.

We do not treat displayed data as a real-time stock or price commitment. The RFQ reply is the verified commercial reference.
