Same Sky (Formerly CUI Devices) ACZ09BR2E-15KQA1-20C10P
ROTARY ENCODER INCREMENT 10PPR
Answer first: this page is a purchasing reference for the exact part number ACZ09BR2E-15KQA1-20C10P from Same Sky (Formerly CUI Devices). Use it to start datasheet, package, manufacturer and RFQ verification; do not treat page text as a live stock, price or lead-time promise.
Key Parameters
| Part Number | ACZ09BR2E-15KQA1-20C10P |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Category | Encoders |
| series | ACZ09 |
| packaging | Box |
| product status | Active |
| param 1 | Not Verified |
| param 2 | Incremental |
| param 3 | Quadrature (Incremental) |
| param 4 | 10 |
| param 5 | 5V |
| param 6 | 6mm Dia Knurled End |
| param 7 | Yes |
| param 8 | Yes |
| param 9 | Panel, PCB Through Hole |
| param 10 | Right Angle |
| param 11 | PC Pin |
| param 12 | 30K |
| param 13 | - |
| param 14 | - |
Parameters are provided for purchasing review. Confirm package, suffix, lifecycle status, datasheet revision and approved substitutes before ordering.
How to Verify ACZ09BR2E-15KQA1-20C10P Before Ordering
Datasheet and parameter checks
- Confirm the full manufacturer part number, not only a shortened search keyword.
- Compare package, pinout, dimensions, voltage or rating fields, temperature range and compliance wording against the released BOM.
- Use the manufacturer datasheet or drawing for electrical and mechanical limits before approving a substitute.
RFQ fields SENICO needs
- Send exact part number, manufacturer, quantity, target delivery date, destination and required packaging.
- State whether alternates are allowed, and list any date-code, certificate, traceability or customer AVL requirement.
- Keep exact stock, factory lead time and proposed alternatives in separate quote lanes.
For ACZ09BR2E-15KQA1-20C10P, SENICO recommends checking manufacturer marking, package, date code, requested quantity, approved vendor requirements and replacement risk before issuing a purchase order. If a supplier suggests an equivalent, record the changed fields and approval owner before comparing price.
We do not treat displayed data as a real-time stock or price commitment. The RFQ reply is the verified commercial reference.
