Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Product Status	Circuit	Switch Function	Current Rating (Amps)	Voltage Rating - AC	Voltage Rating - DC	Actuator Type	Mounting Type	Termination Style	Ingress Protection	Features	Operating Force	Release Force	Operating Position	Pretravel	Differential Travel	Overtravel	Operating Temperature
D2VW-01L3-1MS SWITCH SNAP ACT SPDT 0.1A 125V Omron Electronics Inc-EMC Div	10	-	RFQ	Datasheet	D2VW	Tray	Active	SPDT	On-Mom	100mA (AC/DC)	125 V	30 V	Lever, Simulated Roller	Chassis Mount	Wire Leads	IP67 - Dust Tight, Waterproof	-	120gf	15gf	0.738" (18.7mm)	0.157" (4.0mm)	0.031" (0.8mm)	0.062" (1.6mm)	-40°C ~ 85°C
X-10GQ-B SWITCH SNAP ACTION SPDT 10A 30V Omron Automation and Safety	96	-	RFQ	Datasheet	X	Bulk	Active	SPDT	On-Mom	10A (DC)	-	30 V	Round (Pin Plunger)	Panel Mount	Screw Terminal	IP00	-	510gf	114gf	0.859" (21.8mm)	0.035" (0.9mm)	0.007" (0.18mm)	0.217" (5.5mm)	-25°C ~ 80°C
Z-15GW2277 SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	25	-	RFQ	Datasheet	Z	Tray	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Solder Lug	IP00	-	180gf	50gf	1.625" (41.3mm)	-	0.031" (0.8mm)	0.094" (2.4mm)	-25°C ~ 80°C
Z-15GW2277-B7-K SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	10	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP00	-	180gf	50gf	1.625" (41.3mm)	-	0.031" (0.8mm)	0.094" (2.4mm)	-25°C ~ 80°C
X0228023 SWITCH SNAP ACTION SPDT 10A 250V Crouzet	33	-	RFQ	Datasheet	83106	Bulk	Active	SPDT (DB/DM)	On-On	10A (AC)	250 V	-	Round (Pin Plunger)	Chassis Mount	Quick Connect - 0.250" (6.3mm)	-	Reset Plunger on Bottom	204gf	-	-	-	-	-	-20°C ~ 85°C
Z-15GQ21 SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	6	-	RFQ	Datasheet	Z	Tray	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Cross Roller Plunger	Panel Mount	Solder Lug	IP00	-	250 ~ 350gf	114gf	1.313" (33.4mm)	0.015" (0.4mm)	0.002" (0.05mm)	0.141" (3.6mm)	-25°C ~ 80°C
Z-01H-B SWITCH SNAP ACT SPDT 0.1A 125V Omron Automation and Safety	87	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-Mom	100mA (AC/DC)	125 V	30 V	Round (Pin Plunger)	Chassis Mount	Screw Terminal	IP00	-	250gf	80gf	0.625" (15.9mm)	0.020" (0.5mm)	0.002" (0.05mm)	0.005" (0.13mm)	-25°C ~ 80°C
SZL-VL-S-D-N-M SWITCH SNAP ACT SPDT 0.5A 380V Honeywell Sensing and Productivity Solutions	63	-	RFQ	Datasheet	SZL-VL-S	Bulk	Active	SPDT (DB/DM)	On-Mom	500mA (AC), 50mA (DC)	380 V	220 V	Round (Pin Plunger)	Chassis Mount	Screw Terminal	IP67 - Dust Tight, Waterproof	-	918gf	-	-	0.080" (2.0mm)	0.060" (1.5mm)	0.138" (3.5mm)	-20°C ~ 70°C
Z-15ESR SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	9	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-On	15A (AC/DC)	125 V	30 V	Round (Pin Plunger)	Chassis Mount	Solder Lug	IP00	Reset Plunger on Bottom	270gf	285gf	1.110" (28.2mm)	0.015" (0.4mm)	-	0.062" (1.6mm)	-25°C ~ 80°C
X-10GW2 SWITCH SNAP ACTION SPDT 10A 30V Omron Automation and Safety	6	-	RFQ	Datasheet	X	Tray	Active	SPDT	On-Mom	10A (DC)	-	30 V	Lever, Roller	Chassis Mount	Solder Lug	IP00	-	145gf	21gf	1.266" (32.2mm)	-	0.118" (3.0mm)	0.158" (4.0mm)	-25°C ~ 80°C
Z-15GW2255-B SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	50	-	RFQ	Datasheet	Z	Tray	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP62	-	200gf	42gf	1.188" (30.2mm)	-	0.031" (0.8mm)	0.094" (2.4mm)	-15°C ~ 80°C
Z-15GW255-B SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	41	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP62	-	130gf	21gf	1.188" (30.2mm)	-	0.062" (1.6mm)	0.158" (4.0mm)	-15°C ~ 80°C
Z-15GW255-B7-K SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	6	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP62	-	130gf	21gf	1.188" (30.2mm)	-	0.062" (1.6mm)	0.158" (4.0mm)	-15°C ~ 80°C
D2VW-01L1B-1MS-0 SWITCH SNAP ACT SPDT 0.1A 125V Omron Electronics Inc-EMC Div	75	-	RFQ	Datasheet	D2VW	Bulk	Active	SPDT	On-Mom	100mA (AC/DC)	125 V	30 V	Lever, Straight	Chassis Mount	Wire Leads	IP67 - Dust Tight, Waterproof	-	60gf	5.099gf	0.600" (15.2mm)	0.354" (9.0mm)	0.080" (2.0mm)	0.125" (3.2mm)	-40°C ~ 85°C
Z-15GW255-B6-106-K SWITCH SNAP ACTION SPDT 15A 125V Omron Automation and Safety	7	-	RFQ	Datasheet	Z	Bulk	Active	SPDT	On-Mom	15A (AC), 6A (DC)	125 V	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP62	-	130gf	21gf	1.188" (30.2mm)	-	0.062" (1.6mm)	0.158" (4.0mm)	-15°C ~ 80°C
BZ-2RW53-A2 SWITCH SNAP ACTION SPDT 15A 125V Honeywell Sensing and Productivity Solutions	62	-	RFQ	Datasheet	BZ	Bulk	Active	SPDT	On-Mom	15A (AC), 500mA (DC)	125 V	125 V	Lever, Straight	Chassis Mount	Screw Terminal	-	-	-	-	1.000" (25.4mm)	-	-	-	-55°C ~ 85°C
X-10GW3-B SWITCH BASIC Omron Automation and Safety	13	-	RFQ	Datasheet	X	-	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
X-10GM2 SWITCH SNAP ACTION SPDT 10A 30V Omron Automation and Safety	20	-	RFQ	Datasheet	X	Tray	Active	SPDT	On-Mom	10A (DC)	-	30 V	Lever, Roller	Chassis Mount	Solder Lug	IP00	-	320gf	50gf	1.266" (32.2mm)	-	0.060" (1.5mm)	0.158" (4.0mm)	-25°C ~ 80°C
X-10GW21 SWITCH SNAP ACTION SPDT 10A 30V Omron Automation and Safety	7	-	RFQ	Datasheet	X	Bulk	Active	SPDT	On-Mom	10A (DC)	-	30 V	Lever, Straight	Chassis Mount	Solder Lug	IP00	-	250gf	32gf	0.815" (20.7mm)	-	0.065" (1.7mm)	0.083" (2.1mm)	-25°C ~ 80°C
X-10GW22-B7D SWITCH SNAP ACTION SPDT 10A 30V Omron Automation and Safety	27	-	RFQ	Datasheet	X	Tray	Active	SPDT	On-Mom	10A (DC)	-	30 V	Lever, Roller	Chassis Mount	Screw Terminal	IP00	-	220gf	35gf	1.266" (32.2mm)	-	0.065" (1.7mm)	0.094" (2.4mm)	-25°C ~ 80°C
